Diesel engine driven high pressure hot and cold water vapor cleaning machine / heavy oil washing machine / deicing machine-CUMOND® Environmental Cleaning Solutions

CUMOND high pressure cleaning equipment and steam cleaning machine in action for eco-friendly cleaning.

Product name	Diesel high pressure hot&cold steam cleaning machine	Model No.	CW-CC200
Water pressure	200kg	Steam pressure	50KG
Water consumption	15L/MIN	Steam flow	3L/MIN
Hot water temperature	100 degree	Preheating time	10 seconds
Steam hose	10M	High pressure hose	10M
Size	1020×750×1020MM	Weight	180KG
Power	9HP	Oil consumption	8L/H

Features:

1. The high-pressure cold water, hot water, steam with three, the world's first!Features:

2. Hot and cold water pressure of 200 kg hot water temperature of 100 degrees, the steam pressure of 50 kg, remarkable!

3. Machine no external power supply, comes with maintenance-free battery-powered, without charge, designed for applications where there is not convenient electric field.

4. The use of high-powered diesel-driven air-cooled horizontal bar, electric start, distinct damping measures, stable and reliable.

5. All copper head, overflow protection, stepless pressure regulation, water filtration precision, ultra-high pressure of 200 kg.

6. diesel combustion heating, special design of the heating coil, cold start 10 seconds out of hot water, heating speed, high efficiency

7. Using electromagnetic induction EMF- combustion system, ignition sensitivity, high thermal efficiency, save fuel consumption than similar products by 30%

8. The fuel-efficient furnace, to ensure a continuous supply of hot water or steam, automatic control of heating, water heating is automatically switched off.

9. The machine has been widely adopted in the Liaohe Oilfield, the maturity, the failure rate is small.

Application:

Oil wells, oil pump surface cleaning, equipment, heavy oil cleaning, ship oil cleaning, field industrial oil cleaning, remove snow and ice in winter season.

Steam Cleaning Principle And Function

CUMOND steam temperature is higher than 100 ℃, Then the temperature dropped, But after heated surface stains reach temperatures significantly higher than the temperature of the surface itself, The result is the formation of thermal tension between the dirt and the surface, Which is steam cleaned easily removed from the surface causes of dirt, The temperature errand stain expansion, Almost automatically from the surface.

steam cleaner machine , car steamer , Carpet cleaning

Steam Cleaning Machine Safety Instructions

1. Read all instructions before you use;

2. In order to avoid injury, please be careful to use when you have children around;

3. Be familiar with the control panel, at least you will know how to stop and start the machine;

4. On time maintenance according to the manual;

5. Do not put the gun directly to the people.keep the nozzle open;

6. Do not open or change the internal wiring when electrical control box without disconnecting the power;

7. Do not place hands or fingers on the front of the gun;

8. Before the repair, maintenance, removal of accessories, please turn off the power supply and release residual pressure;

9. Please wear work clothing: waterproof overalls, rubber shoes, eye protection and insulated gloves;

10. Do not spray on the electrical equipment and wiring;

11. Grounding description: electric drive or electric heating equipment must be grounded. If it malfunctions or failure,grounding to prevent electric shock. Improper grounding will cause electric shock.

If you have questions about grounding mouth, then ask a professional electrician check.

Do not modify the wife of the electrical plug (if it does not apply to electrical outlet),

So find a qualified electrician to install, Do not use any converters.

About The Use Of Location

1. Washing machine works best when placed on a flat surface and fixed;

2. Proper drainage;

3. To be avoid the harsh weather when you use the machine at outside.

About Power Configuration

1. It is very important to keep adequate power supply for this machine. Please provide the consistent power configuration;

2. If any error on the machine, protective devices on the line to be sensitive;

3. The electrical configuration of equipment installed by a qualified electrician,

in accordance with the relevant rules of national standards to operate;

4. For safety equipment and operator of reasons, we recommend the use of ground-fault current protection;

5. This machine has a maximum rated current value (A).

About Water Configuration

Please do not use muddy, sandy river water, to avoid clogging of the filter when the water inlet ;

1. In any case of the water supply should be 150% rating. If ratings apparatus is 10 liters per minute, then the water supply is 15 liters per minute;

2. When the shortage of water supply, water equipment will stop working until the water level rises, then start the reset button;

3. The water quality in some of countries is not good. It is easy to produce scale. Please contact your local water inspection department for assistance;

4. Be careful not to use rusty, sandy or containing impurities water.
