Air Blade / Vibration Whip (2-in-1) CW-T205

Consisted of front and rear color video cameras (with high intensity illumination), auto jib-arm for dust collecting and sampling, movement on tracked or four-wheel drive mechanism.The service provide

  • Brand: CUMOND
  • Model: CW-T205
  • Warranty: 12 months
  • Packing: Wooden case/wooden pallet


  • Consisted of front and rear color video cameras (with high intensity illumination), auto jib-arm for dust collecting and sampling, movement on tracked or four-wheel drive mechanism.

  • The service provider will be able to judge the interior condition of the air duct and to devise a customized cleansing proposal for the Owner’s approval.

  • When fitted with the special shoveling device, this robot can move heavy items such as bricks, rocks or abandoned tools to the exit of access panels for discard.

  • Video can be recorded as needed.


Technical Data:

Dimensions: 1,700mm (L) x 200mm (W) x 180mm (H)

Weight: 12 kg

Types and Materials of Air Ducts to be cleaned: Large rectangular or square air ducts made of metal or composite materials.

Operating Air Pressure: 0.6MPa~1.2MPa.

Range of Cleaning: Height 30~2,000mm x Width 30~2,000mm, and if round duct diameter could be 30~2,000mm.

Standard Provisions:

6 numbers of 1.5m rigid air tubes and 12 numbers of 1.5m flexible air tubes, all equipped with quick disconnect.

One each of front blowing nozzle, rear blowing nozzle and centre blowing nozzle.

One each of front blowing whip, rear blowing whip and standard vibration whip.

One manual control gun type valve and two reels of flexible high pressure air connecting hose.

A combined support stand used for large air duct cleaning (including a combined support stand used for the camera).

Optional Provisions:

Complete set of synchronous monitoring and recording system.

Complete set of rotational and spraying sterilizer and high intensity UV bactericidal lamp.
