Special high speed motor, working mode can be either “raised dust absorption” or “direct dust absorption”. Effective operating range up to 30 meter.Working voltage 220V ac/50hz, compact and light weig
Special high speed motor, working mode can be either “raised dust absorption” or “direct dust absorption”. Effective operating range up to 30 meter.
Working voltage 220V ac/50hz, compact and light weight.
Comprehensive indicating panels to include on/off indication, voltages and current consumption of motor, filter resistance alarm, overload, overheat and leakage protection.
3 stage filter efficiency, 99.7% trap rate for particles with a size of not smaller than 0.3mm.
Concentration of emission: Concentration of PM10 particles in the exhaust air shall not be more than 0.15 mg/m3.
Technical Data:
Dimensions: 1,080mm (L) x 430mm (W) x 930mm (H)
Weight: 48 kg
Operating Voltage: 220V ac/50hz
Power: 4,000W
Dust Absorption Mode: Can be either “raised dust absorption method” or “direct dust absorption method”
Maximum Vacuum: 650 Pa for “raised dust absorption methodand” 20,000 Pa for “direct dust absorption method”
Filter Efficiency: 99.7% for particles with a size of not smaller than 0.3mm.
Concentration of Emission: Content of PM10 particles shall not be more than 0.15mg/m3.
Display and protection: Equipped with multiple protection system... “meters to show voltages and current consumption of fan motor, filter resistance alarm, fan overload, overheat and current leakage alarm.
